Basic Information
Model advantages
1. The U-type machine uses a counter-balanced mold clamping frame structure, which is matched with the linear guide rail of a famous Taiwan factory; it makes the motion of the mold base faster and more stable, and the clamping force is stronger and more uniform;
2. It can realize 16 inserting pens perpendicular to the pen inserting hole of the mold at the same time;
3. Computer intelligent control system, easy to operate, set and modify production procedures;
4. The inside of the die head adopts deep mirror surface treatment, the curved flow channel is smooth, no dead angle, no carbon deposit;
5. Reinforced and hardened cold-treated screw, the screw barrel is wear-resistant;
6. Japanese CNC machine tools are used to produce various components, and Mazak six-sided integrated machining center is used to process all mounting surfaces of components at one time, and imported hydraulic, pneumatic and electrical components of famous brands are selected to ensure that the model has rigorous technology and stable and reliable quality. .

Model performance characteristics
1. It is suitable for the production of plastic hollow products made of PE, PP, EVA, ABS, K material, TPU, nylon and other materials below 5L;
2. Computer intelligent control system, Chinese and English operation interface;
3. According to the characteristics of different plastics, different screw, die mandrel and runner styles can be designed;
4. The mold head is easy to change material, color, slag discharge, disassembly and cleaning, and the wall thickness of the symmetrical part of the tube blank is very uniform;
5. The dual proportional valve controls the flow rate and pressure of the oil circuit, the reversing valve controls the flow direction, the deceleration valve brakes, and the action is smooth and fast;
6. Toggle-type clamping structure, the front and rear of the formwork center are designed to ensure the uniformity of the clamping force;
7. Liftable extrusion platform, easy to adjust the length of the blank
8. CE standard safety design, focusing on user safety;
9. The Japanese frequency converter adjusts the screw speed to save electricity and energy;
10. Automatic lubrication system reduces equipment maintenance workload.

Model optional features
1. For the convenience of material return, the user can choose to add a hydraulic automatic filter screen device, which can be added with a down blowing, wall thickness controller, automatic bottom pulling or automatic flash removal device;
2. Optional pre-sealing cutter, horizontal cutter, imported hot cutter, cold cutter, etc.;
3. Optional oblique pen, bottom pen, blowing pen, auxiliary cooler, etc.;
4. Thickness controller is optional;
5. Optional permanent magnet brushless DC motor independently developed by Leshan Machinery for plastic hollow molding machines: high reliability, good stability, comprehensive energy saving of 8% to 15%;
6. Optional polymer mixing screw: while ensuring the performance of the product, it can save 15%-30% of raw materials;
7. The Austrian SIGMATEK control system is optional, and its command execution speed is ten times that of the traditional cycle refresh mode;
8. Optional remote after-sales service system: automatic fault analysis and diagnosis, maintenance records, report statistics, video transmission, remote mobile phone SMS notification and alarm, etc., all in one machine, clear in the chest;
9. Optional dust-free air delivery system, conveyor belt, automatic feeding system, 4-in-1 feeding machine and other supporting functions;
10. Mold thimble function, in-mold labeling function, online leak detection function, and cover opening and closing function are optional;
11. Front and rear mobile platforms are optional, which is convenient for mold installation;
12. Optional pre-clamp function, 2-axis servo manipulator, single-axis servo manipulator;
13. Users can choose shunt shuttle, spiral or glue discharge die head, continuous extrusion die head and storage die head according to their preferences.
14. It can be equipped with a super-large pen blowing function to quickly increase production.
15. Manipulator is optional, which integrates the functions of secondary air blowing for sizing and air blowing for leak detection.
16. Optional gong mouth machine (inside machine and outside machine) can meet the needs of different product sizes to make the bottle mouth of the product smoother.

Model operation and precautions
1. Preparation before production
1.1 Check whether the machine has any parts or components damaged, check whether the screws are loose, check whether the wires and cables are damaged or fall off, and if damaged, replace or repair them in time; check whether there are sundries in the hopper of the extruder and clean them up, Then close the material gate.
1.2 Check whether the moving parts are firm, whether the screws are loose and fall off, especially where the impact is strong, and whether the belt transmission part is abnormal.
1.3 Check whether the high-pressure air source, low-pressure air source, power supply, and water source are normal.
1.4 Check whether the emergency stop switches, safety door switches, and protection device detection switches are normal.
1.5 Check whether each pneumatic component is leaking and whether the action is sensitive.
1.6 Please strictly follow the procedures in the operation manual.
2. Normal production
When the machine is in normal production, a special person is required to take care of it, and if any problems are found, they should be dealt with in time. Due to the high degree of automation of the machine, the workload during normal production is very small. The user only needs to add raw materials regularly, and use containers to collect finished products and scraps at the designated positions of the machine.

Product care and maintenance
Free domestic installation and commissioning, 1-year free warranty and permanent equipment maintenance service. And has a professional outbound maintenance team.
