Die head: verticality first-in first-out system;
Extruder unit: adopt automatic temperature control unit of import,the screw united by hard tooth surface gear box and frequency motorto achieve stepless speed regulation;
Clamping device: the clamping device of double draw bar is a type of hydraumatic and fixed , draw bar of new type through template,this type is accommodate large size of mould,smooth action,high stability,clamping mould force is uniformly,template is not distortional;
Hydraulic system: whole system adopt imported components,proportional pressure,flow,pressure feedback,system response is faster,action is more smoothly,lowest power loss,and the output of torque is big.
Electric controlling system: it adopts Japan programmable controller,touch screen,the characteristic of it has direct manipulation and large information on board.
| Max. Product Volume | L | SX-S260L |
| Dry cycle | PC/H | 300 |
| Screw diameter | MM | 120 |
| screw L/D ratio | L/D | 28-32 |
| screw motor power | KW | 90-132 |
| screw heating capacity | KW | 22 |
| No. of heating zone | Zone | 6 |
| output of HDPE | KG/H | 320-380 |
| oil pump driver power | KW | 45 |
| clamping force | KN | 900 |
| mold stroke | MM | 720-1800 |
| size of mold(W*H) | MM | 1300-1600 |
| Moving distance | MM | 600 |
| Max. Die diameter(W*H) | MM | 15 |
| Die heat capacity | KW | 22 |
| Blowing pressure | MPA | 0.8 |
| Air volume | M3/Min | 3 |
| Cooling water pressure | MPA | 0.3 |
| water consumption | L/Min | 250 |
| weight of machine | Ton | 35 |
| size of machine | M | 7.8*2.9*5.4 |
Hydraulic system:Proportional Pressure Control,equipped with imported famous brand
hydraulic valve and pump,stable and reliable
Plsticization system:Efficient plasticizing mixing screw. Ensure plastic plasticizing
completely and evenly.
Speed regulating system:frequency control and hard alloy tooth surface reducer casing.
Smooth speed,energy saving,low noise and durable
Molding clamping sliding structure adopts linear guidr way. Accuracy up to micron level .The whole mold clamping combining a high position accuracy , easy and energy saving ,and strong bearing,immutability.Patented products:three rod,single cylinder two-way synchronous mold clampimg structure,stability is good.
Adopting the parison programmer.reducing the differences on the width of the up and down due to reducing material and vertical tensile,and improve the uniformity of the wall thickness efficiently.
Die-mold:Using the best quality material,like 38CrMoAIA,42CrMov,35CrMo,Through precision maching and heat treatment
Mold changing more easy:the die-mold can be lift up and down,backward and forward with the machine plate(hydrauloc cpmtrol).for saving more space to install all kinds of molds.die-mold up and down.for adjusting the mold mouth and the mold distance.reduce the material waste.
Energy saving:while the speed is 70％of the nominal speed,the power consumption is 110kw/h,and energy saving 20kw/h than the old machines.
